Single Products

1. 25±2℃, charging at 0.5C, discharging at 1C, 90%DOD (SOC range: 100%~10%), cycle to 80% of nominal capacity.

2. 25±2℃, charging at 0.5C, discharging at 0.5C, capacity≥80%.

3. The actual output power is reduced with the temperature: From 30℃ to 50℃; the actual output power will be reduced by 5% for each 1℃ increase.

• Excellent dust-proof performance with separate compartment design
• Intuitive display of battery SOC via 5-bar indicator lights
• Build-in bluetooth module
• Optional 4G or WiFi module to remote control the inverter/charger by the RS485 com. port
• Circuit breaker on PV input for equipment safety
• AC charging with PFC technology, high power factor for efficient energy consumption
• Advanced MPPT technology: maximum tracking efficiency≥99.5%
• Long-term continuous operation at full power
• Comprehensive electronic protection

• Built-in LiFePO4 lithium battery
• Multiple DC output ports (5VDC/3A ports, 12VDC/2A ports, Type C ports)
• Large-sized LCD screen to monitor and modify system parameters
• AC input overload relay for disconnecting from the grid when the fault occurs
• Circuit breaker on battery output for battery safety
• Bidirectional high-frequency transformer isolation topology
• EMC design on AC output to avoid interference with AC load
• Pure sine wave output
