IT-NC G3 Series (50~100A) MPPT Charge Controller with Load Control

Description

The IT-NC G3 Series MPPT Charge Controller is designed for off-grid solar systems that need both efficient solar charging and reliable DC load power. Unlike standard MPPT controllers, this model not only charges batteries efficiently but also directly powers DC loads, making it ideal for applications like solar streetlights, RVs, boats, and remote monitoring systems.

With 50A-100A charging capacity, 99.9% MPPT tracking efficiency, and dual PV input options (select models), this controller maximizes solar energy utilization. Some models come with a built-in BLE Bluetooth module, allowing for seamless wireless monitoring via a mobile app. Its intelligent load control supports multiple operation modes, ensuring stable power supply to DC devices. Remote monitoring is effortless via RS485, with optional Bluetooth, WiFi, or 4G modules for real-time data access.

Built with a durable metal housing and IP32/IP43 protection, the IT-NC G3 ensures long-lasting performance in various off-grid environments. Whether you need reliable DC power for solar lighting, RV appliances, or industrial equipment, this MPPT controller with load output delivers smart, efficient, and versatile solar power management.

Additional Information

Model	IT5420NC G3	IT6415NC G3 IT6415NC G3 BLE	IT6420NC G3	IT7415NC G3	IT7420NC G3	IT8420NC G3	IT10415NC G3 IT10415NC G3 BLE	IT10420 NC G3
Electrical Parameters
Battery Rated Voltage	12/24/48VDC~Auto
Controller Operating Voltage Range	8–62V
Battery Type	AGM (Default) / Gel / Flooded / User
Lithium Battery Type	LiFePO4 / Li (NiCoMn)O2 / User
Rated Charging/Discharging Current	50A	60A		75A		80A	100A
Rated Charging Power	650W/12V 1300W/24V 2600W/48V	780W/12V 1560W/24V 3120W/48V		975W/12V 1950W/24V 3900W/48V		1040W/12V 2080W/24V 4160W/48V	1300W/12V 2600W/24V 5200W/48V
Maximum Charging Power	650W/12V 1300W/24V 2600W/48V	780W/12V 1560W/24V 3120W/48V		975W/12V 1950W/24V 3900W/48V		1040W/12V 2080W/24V 4160W/48V	1300W/12V 2600W/24V 5200W/48V
Rated Load Current	50A	60A		75A		80A	100A
Maximum Load Current	50A	60A		75A		80A	100A
PV Maximum Open-circuit Voltage	200V (@ lowest temperature); 180V (@ 25℃)	150V (@ lowest temperature) 138V (@ 25℃)	200V (@ lowest temperature) 180V (@ 25℃)	150V (@ lowest temperature) 138V (@ 25℃)	200V (@ lowest temperature) 180V (@ 25℃)	200V (@ lowest temperature) 180V (@ 25℃)	150V (@ lowest temperature) 138V (@ 25℃)	200V (@ lowest temperature) 180V (@ 25℃)
MPPT Operating Voltage Range	(Battery voltage plus 2V, and > 28V) to 144V (@ 25 ℃)	(Battery voltage plus 2V, and > 28V)to 108V (@ 25℃)	(Battery voltage plus 2V, and > 28V) to 144V (@ 25 ℃)	(Battery voltage plus 2V, and > 28V) to 108V (@ 25 ℃)	(Battery voltage plus 2V, and>28V) ~144V (@ 25 ℃)		(Battery voltage plus 2V, and > 28V) to 108V (@ 25 ℃)	(Battery voltage plus 2V, and > 28V) to 144V (@ 25 ℃)
Tracking Efficiency	≥ 99.5%
Maximum Conversion Efficiency	98.3%	98.6%	98.1%	98.6%	98.1%	98.5%	98.6%	98.5%
Full Load Efficiency	97.1%	98.0%	98.0%	98.0%	97.5%	97.5%	98.0%	97.6%
Temperature Compensation Coefficient	-3mV/℃/2V (Default)
Self-consumption (Enabled Communication)	98mA/12V; 60mA/24V; 46mA/48V
Self-consumption (Disabled Communication)	48mA/12V; 25mA/24V; 14mA/48V
Grounding Type	Common negative grounding
Dry Contact (Oil Generator / Utility)	Rated value: 5A/30VDC; Maximum value: 0.5A/60VDC
RS485 Communication Port	5VDC/200mA (RJ45)
Mechanical Parameters
Dimension (Length × Width × Height) IP43 (Controller & White Terminal Cover)	307 × 253 ×143mm	320 × 263 ×143mm		320 × 263 ×158mm		352 × 263 ×158 mm	352 × 263 ×158mm
Dimension (Length × Width × Height) IP32 (Controller Only)	307 × 202 ×134mm	320 × 212 ×134mm		320 × 212 ×149mm		352 × 212 ×149 mm	352 × 212 ×149mm
Mounting Dimension (Length × Width)	295 × 130mm	308 × 140 mm				340 × 140 mm
Mounting Hole Size	Φ7mm
Wiring Terminal	6AWG/16mm²	2AWG/35mm²
Recommended Cable	6AWG/16mm²			4AWG/25mm²			2AWG/35mm²
Net Weight IP43 (Controller & White Terminal Cover)	5.07kg	5.88kg	5.93kg	6.56kg	6.62kg	7.79kg	7.87kg	7.87kg
Net Weight IP32 (Controller Only)	4.86kg	5.66kg	5.71kg	6.34kg	6.40kg	7.55kg	7.63kg	7.63kg
Environmental Parameters
Operating Temperature Range	-25℃ to +60℃ (Derating when temperature is higher than 40℃)
LCD temperature range	-20℃ to +70℃
Storage Temperature Range	-30℃ to +70℃
Relative Humidity	5%–95% (N.C)
Altitude	< 5,000M (Derating when altitude is higher than 2,000m)
Enclosure	Ip43 (Controller & White Terminal Cover); IP32 (Controller Only)
Pollution Degree	PD2
Certification
Safety	EN/IEC62109-1
EMC	EN61000-6-1 / EN61000-6-3
FCC	47 CFR Part 15, Subpart B
ROHS	IEC62321-3-1

Downloads

Datasheet

IT-NC G3 Series (50-100A)-Datasheet-EN

Download File

Manual

IT-NC G3 Series (50-100A)-Manual-EN-V1.1

Download File

Highlights

Product Highlights

Supports 12V/24V/36V/48V systems; Charge/Discharge current: 50A–100A
All metal die-casting shell, IP43
Some models supports two PV inputs
Max. MPPT tracking efficiency: 99.9%; Max. Conversion efficiency: 98.5%
Compatible with AGM, Gel, Flooded, LiFePO4 batteries, etc.
Constant voltage output function: Enables direct load supply with sufficient PV energy
Communication interface with electrical isolation
CAN: Parallel operation of up to 6 devices (with or without batteries)
BMS: Ensures reliable lithium battery charge/discharge management
RS485: Optional Bluetooth, WiFi, or 4G modules
Real-time data recording, event logging, and power statistics function
EMC compliant (CLASS B)
